3D Corrugated Steel Structuer

3D wave arc, excellent seismic performance;

Suitable for high fill, large longitudinal slopes and other terrains, with strong structural stability

This project design is a low arch in a large span, as we know, the span is big, the rise is small, it will be a challenge for the strength of the corrugated steel structure, the small radius of arch shoulder is a problem to affect the arch strength.

To be instead of traditional corrugated steel structure design, we adopt 3D wave, it is stronger, even small radius arc, it also can keep good strength performance.

The profile shape of the arch is a box shape, with 3D wave, it can meet the strength calculation.
